Submersible Water Level sensor

Product Description

Parameter :Specification

Measuring Range: 0–200 m

Overload Pressure: 200% FS Comprehensive

Accuracy: ±1%, ±0.5%, ±0.2%, ±0.1%

Temperature Drift :±0.03%/°C Temperature

Range :-10°C to 70°C Long-term Stability :±0.3%

FS/year Working Temperature: -40°C to 85°C

Storage Temperature: -40°C to 125°C Output

Signal: L0–10V / IIC / 4–20mA / RS485

Supply Voltage :10–36V / 3.0–5.5V Load

Resistance :≥10KΩ / ≤50(U–10) Protection Level

:IP68 Media Compatibility: Various noncorrosive fluids Vibration Resistance 10g RMS

(20–2000Hz)

Shock Resistance :100g, 11ms Insulation

Resistance: >100MΩ @250VDC

Response Time: Certification CE (EMC:

IEC61326-1 Class B)
